Product Details:
Payment & Shipping Terms:
|
| Name: | Touch Screen Smart Board | Resolution: | 3840 * 2160 |
|---|---|---|---|
| Android Version: | Android V8.0 | Application: | Education |
| RAM: | 4g | Working Principle: | Ultrasonic And Infrared Interactive Whiteboard |
| PC Interfaces: | HDMI Out*1;USB3.1 Gen1 Type-C*1;USB 2.0*2;USB 3.0* | Camera Pixel: | 8million Pixels |
| Feature: | Multi Finger Touch | ||
| High Light: | 110" IR interactive whiteboard,anti scratch interactive whiteboard,Android 9.0 touch screen smart board |
||
Android 9.0 Touch Screen Smart Board 65" 75" 85" 98" 100" 110" IR Interactive Whiteboard Smart Board
Interactive Whiteboard Specification
| Input/Output Interface | RS232 | 1 |
| YPBPR IN | 1 | |
| HDMI IN | 2 | |
| RJ45 | 2 | |
| Touch usb | 1 | |
| VGA IN | 1 | |
| VGA AUDIO IN | 1 | |
| SD card | 1 | |
| MIC IN | 1 | |
| USB 3.0 | 2 | |
| AV IN | 1 | |
| RF-IN | 1 | |
| Output | SPDIF OUT | 1 |
| EARPHONE | 1 | |
| AV OUT | 1 | |
| Frontial Interface | USB Touch | 1 |
| USB 2.0 | 3 | |
| HDMI | 1 | |
| Touch Screen Specification | Touch Point | SoftTouch sensitive Real 10 points touch |
| Touch Type | Latest Version Infrared Ray Touch | |
| Touch Sensibility: | <2mm | |
| Response Time | <2ms | |
| Scanning Rate | 50 scans/s | |
| Available object size for touch | 2mm | |
| Transparency of Tempered protecting glass | >97% | |
| Durability of Touch | No limited | |
| Surface hardness of Touch screen | Mohs 7th level ,and bearable with the hit of 6kg weight of metal ball |
Interactive Whiteboard​ features
♦ Ultra narrow high tensile aluminum frame with painting treatment,anti scratch and low weight.
♦ Arc plastic conner designed for kids protection.
♦ Aluminum honeycomb/ceramic board with Nanometer high molecule surface,which is smooth and anti-scracth.Water-based marker is available.
♦ Moduled PCB parts designed,easy to seperate and disassemble,easy to maintain.
♦ Power supply by USB cable,plug and play with no driver.
♦ Wall mounted and floor stand.
♦ Regular size:83"/84"/88"/92"/96"/100" with 4:3/16:9 aspect ratio choices.
♦ OEM size from 50" to 120"acceptable.
Interactive Whiteboard function
1. Common interface front, speaker front, digital audio output, support full-channel touch, touch channel automatic switching, gesture recognition, smart control, remote control integrated computer shortcut keys, smart eye protection, one-key switch;
2. Optional built-in camera, remote participants can see the scene during the network video conference;
3. Optional built-in array microphone function, during network video conference, both on-site and remote can hear the voice of each other's explanation;
4. Detachable infrared frame structure design;
5. Optional high-precision 20-point real touch with an accuracy of 1mm.
Details
