Product Details:
Payment & Shipping Terms:
|
| Name: | Touch Screen Smart Board | Resolution: | 3840 * 2160 |
|---|---|---|---|
| Android Version: | Android V8.0 | Application: | Education |
| RAM: | 4g | Working Principle: | Ultrasonic And Infrared Interactive Whiteboard |
| PC Interfaces: | HDMI Out*1;USB3.1 Gen1 Type-C*1;USB 2.0*2;USB 3.0* | Camera Pixel: | 8million Pixels |
| Feature: | Multi Finger Touch | ||
| High Light: | 4K smart board interactive whiteboard,Android V8.0 smart board interactive whiteboard,Multi Finger Touch interactive smart board |
||
School Smart Board Touch Interactive Education Whiteboard 4K Digital White Board Electrical Teaching Board
Interactive WhiteboardSpecification
| Touch Screen Specification | Touch Point | SoftTouch sensitive Real 10 points touch |
| Touch Type | Latest Version Infrared Ray Touch | |
| Touch Sensibility: | <2mm | |
| Response Time | <2ms | |
| Scanning Rate | 50 scans/s | |
| Available object size for touch | 2mm | |
| Transparency of Tempered protecting glass | >97% | |
| Durability of Touch | No limited | |
| Surface hardness of Touch screen | Mohs 7th level ,and bearable with the hit of 6kg weight of metal ball | |
| Panel Specification | Panel Brand | LG / SAMSUNG /BOE / Chimei Original A+Grade panel A + grade, without any light spot or black spot and Full Viewing Angle |
| Max Resolution | Ultra-HD 4K 3840*2160 | |
| Panel color | 16.7 Millinium | |
| Pixel Pitch(mm) | 0.2835(H)×0.2835(V) ~0.4833(H)×0.4833(V) | |
| Brightness (nits) | 350~400cd/m2 | |
| Contrast | 1500:1 | |
| Visual angle | Full View 178/178 degreee | |
| Response time | 3~5ms | |
| Life(hrs) | >60,000(hrs) | |
| Brightness (nits) | 350~400cd/m2 | |
| Contrast | 1500:1 | |
| Visual angle | Full View 178/178 degreee | |
| Response time | 3~4ms | |
| Life(hrs) | >60,000(hrs) |
Interactive Whiteboard​ features
♦ Ultra narrow high tensile aluminum frame with painting treatment,anti scratch and low weight.
♦ Arc plastic conner designed for kids protection.
♦ Aluminum honeycomb/ceramic board with Nanometer high molecule surface,which is smooth and anti-scracth.Water-based marker is available.
♦ Moduled PCB parts designed,easy to seperate and disassemble,easy to maintain.
♦ Power supply by USB cable,plug and play with no driver.
♦ Wall mounted and floor stand.
♦ Regular size:83"/84"/88"/92"/96"/100" with 4:3/16:9 aspect ratio choices.
♦ OEM size from 50" to 120"acceptable.
Interactive Whiteboard function
1. Common interface front, speaker front, digital audio output, support full-channel touch, touch channel automatic switching, gesture recognition, smart control, remote control integrated computer shortcut keys, smart eye protection, one-key switch;
2. Optional built-in camera, remote participants can see the scene during the network video conference;
3. Optional built-in array microphone function, during network video conference, both on-site and remote can hear the voice of each other's explanation;
4. Detachable infrared frame structure design;
5. Optional high-precision 20-point real touch with an accuracy of 1mm.
